Ourmeter LCD-S700 - Instrument Specification Parameters; Power Supply Voltage; Rated Working Current; Maximum Working Current

www.cyrusher.com
28 / 29
7 Instrument specification parameter
1）24V，36V，48V power supply
2）Rated working current 10mA
3）Maximum working current of meter 30mA
4）Shutdown leakage current is less than 1uA
5）Supply controller side working current 50mA
6）Temperature: - 18 ~ 65 ℃
7）Storage temperature: - 30 ~ 80 ℃
vjh
8 Error code definition
S700 can provide warning for the vehicle fault, in the LCD shows the ERROR icon
when a failure is detected, the position ERROR code displayed ERROR code n, n = 0
~ 11 shows ERROR, ERROR code comparison table 1 table as shown below
Status code
（decimalism）
State Process mode
0 normal
6 Battery under voltage Battery charge
7 Motor fault Check whether the power
line is loose
8 Handle fault Check the links, if it is
normal, then replace the
handle
9 Controller fault Check the links
10 Reception fault Check the links of the
instrument cable
11 Communication fault Check the links of the
instrument cable
