Table8.1: SYNC_PULSE_INInterfaceRequirements
Parameter MinVoltage MaxVoltage MinDriverCurrent
LOGICLOW -30V 2V N/A
LOGICHIGH 2.9V 30V 3mA @3.3V~5V, 5mA
at24Vandhigher
Table8.2: MULTIPURPOSE_IO-INPUT InterfaceRequirements
Parameter MinVoltage MaxVoltage MinDriverCurrent
LOGICLOW -30V 2V N/A
LOGICHIGH 2.9V 30V 3mA @3.3V~5V, 5mA
at24Vandhigher
8.3 ConfiguringtheOusterSensor
PleaserefertotheGPSconfigurationsectioninthesoftwareusermanualtoconfigureyoursensorto
synchronizeitstimestampwith theGPS.
9 Support
Incaseofanyquestionsregardingthecontentsofthisusermanualortheconfigurationofthesensor,
pleasereachout to
support@ouster.ioorvisitOusterwebsite.
