Ouster OS2 - Mechanical Interface; Included Components

3 MechanicalInterface
3.1 IncludedComponents
TheOS2isshippedwiththefollowingitems:
OS2-128,OS2-64,orOS2-32
Sensortointerfaceboxcable/connector
InterfaceBoxand 24VAC/DCpowersupply(2meters)
RJ45cable(1meter)
BaseplateMount
Figure3.1: SensorComponents
DownloadableCADfiles forthe OS2canbe foundonline atOusterDownloadPage
Warning: ThewateringressprotectionratingforthesensorisonlyvalidiftheI/Ocableisplugged
intothepanelmountconnectoron the base of the sensor, and the locking collet rotatedpast the
détente click to the properly locked condition i.e past the détente position. The cable and plug
arean elementofthe sensoringress protectionsystem. Without theconnectedcabletheingress
