Outback Comet Kettle K102 - Parts List

2
Parts List
Quantity varies according to model purchased. Specifications subject to change without prior notice. For
more details on hardware, please see the corresponding ‘Hardware Reference Diagram’.
 Pre-Assembled Component
CODE PART QTY
Outback® Comet
Kettle Charcoal BBQ
HOOD
A1 Hood 1
3
A2 Hood Hook 1
3
A3 Handle 2
3
A4 Hood Air Vent 1
3
A5 Heat Indicator 1
3
BODY
B1 Barbecue Body 1
3
B2 Charcoal Grill 1
3
B3 Cooking Grill 1
3
B4 Small Cooking Grill 1
3
B5 Grill Bracket 3
3
B6 Grill Lifting Handle 2
3
B7 Ash Tray Bracket 1
3
B8 Ash Tray 1
3
B9 Air Vent 1
3
TROLLEY
C1 Front Leg 1
3
C2 Left Rear Leg 1
3
C3 Right Rear Leg 1
3
C4 Leg Support Rack 1
3
C5 Wheel 2
3
C6 Wheel Hubcap 2
3
HARDWARE
D1 M6x12 Bolt 11
3
D2 M6 Nut 11
3
D3 M8 Nut 1
3
D4 M6 Washer 10
3
D5 M5x12 Bolt 4
3
D6 M5 Nut 4
3
D7 Axle Nut 2
3
