Outback EX200T User Manual

2
Parts List
Quantity varies according to model purchased. Specifications subject to change without prior notice. For
more details on hardware, please see the corresponding ‘Hardware Reference Diagram’.
 Pre-Assembled Component
 Quantity varies according to model purchased
 Appearance, size, and construction may differ according to model purchased
CODE PART QTY
OUTBACK®
EXCEL 200 GAS
OUTBACK®
EXCEL 300 GAS
HOOD
A1 Hood (Pre-Assembled to Body) 1
√ √
A2 Hood Handle 1
√ √
A3 Warming Rack 1
√ √
BODY
B1 Barbecue Body 1
√ √
B2 Burner 1
√ √
B3 Control Panel 1
√ √
B4 Knob (Pre-Assembled) 2
√ √
B5 Hose and Regulator Assembly 1
√ √
B6 Lava Rock in Basket 1
√ √
B7 Cooking Grill 1
√ √
B8 Ignition Button (Pre-Assembled) 1
√ √
B9 Control Panel Heat Shield 1
√ √
B10 Main Electrode 1
√ √
B11 Hinge Bracket (Pre-Assembled) 2
√ √
B12 Body Heat Shield 1
√ √
B13 Body Support 2
√ √
B14 Grease Cup Holder 1
√ √
B15 Grease Cup 1
√ √
C1 Side Shelf (with bracket)

1
C2 Side Shelf (without bracket) 1
√ √
C3 Side Shelf Bracket A 1
√ √
C4 Side Shelf Bracket B 1
√ √
C5 Side Burner Knob

1
C6 Side Burner Grid

1
C7 Side Burner Shelf

1
C8 Side Burner

1
C9 Side Burner Electrode

1
C10 Side Burner Valve / Hose Assembly

1
C11 Left Front Leg 1
√ √
C12 Left Rear Leg 1
√ √
C13 Right Front Leg 1
√ √
C14 Right Rear Leg 1
√ √
C15 Hose Tidy 1
√ √
C16 Gas Bottle Holder 1
√ √
C17 Leg End Loop 1
√ √
C18 Wheel Spacer 2
√ √
C19 Wheel 2
√ √
C20 Axle 1
√ √
C21 Bottom Shelf 1
√ √
C22 Gas Bottle Strap 1
√ √
HARDWARE
D1 M6x15 Bolt 28
√ √
D2 M5x10 Bolt 4
√ √
D3 M4x10 Bolt

1
D4 ST4.0x10 Screw 7
√ √
D5 ST4.0x15 Screw 4
√ √
D6 ST4.8x15 Screw 2
√ √
D7 M8 Locknut 2
√ √
D8 M5 Nut 2
√ √
D9 Spacer

10 6
TROLLEY

Outback EX200T Specifications

General

Brand	Outback
Model	EX200T
Category	Grill
Language	English
