Outback Excel 100T User Manual

12
Attach the Hood Handle (A2) to the Hood (A1) using
the M5x10 Bolts (D2).
Carefully place the Barbecue Body (B1) onto the tops of the legs.
Attach the barbecue body to the trolley assembly using the M6x15 Bolts (D1). Ensure the tabs on the
body fit over the legs as shown in the diagram and do not go down inside of the legs.
WARNING: DO NOT RELEASE THE BARBECUE BODY WHILE THE BARBECUE HAS NOT BEEN
PROPERLY SEATED. THIS MAY RESULT IN INJURY OR DAMAGE TO YOUR BARBECUE.
8
7
 Excel 100T Excel 200T Excel 300T
 Excel 100T Excel 200T Excel 300T
A2
A1
D2
B1
D1
