18
Attach the Side Burner Shelf (C8) to the left front and left rear legs using M6x15 Bolts (D1).
Remove the screws from Side Burner
Valve / Hose Assembly (C11) and se-
cure it to the side shelf with those 2
screws.
Assemble the Side Burner Knob (C6)
onto the side burner valve.
Excel 200T users, skip this step and proceed directly to step 24.
20
19
Excel 100T Excel 200T Excel 300T
Excel 100T Excel 200T Excel 300T
C8
D1
C6
C11
To Next Page
