2
CODE PART QTY
Outback®
Jupiter 4 Burner Gas BBQ
HOOD
A1
Hood (Pre-Assembled to Body)
1
A2 Hood Handle 1
A3 Heat Indicator 1
A4 Warming Rack 1
BODY
B1 Barbecue Body 1
B2 Burner 4
B3 Control Panel 1
B4 Knob 4
B5 Hose and Regulator Assembly 1
B6 Large Lava Rock in Basket 1
B7 Small Lava Rock in Basket 1
B8 Grill W ith Hole 1
B9 Round Grill 1
B10 Cooking Grill 1
B11 Drip Tray Left Bracket 1
B12 Drip Tray Right Bracket 1
B13 Drip Tray 1
B14 Drip Pan 1
B15 Ignition Button 1
TROLLEY
C1 Side Burner Shelf 1
C2 Side Burner Shelf Panel 1
C3 Side Shelf 1
C4 Side Shelf Panel 1
C5 Tool Hook 1
C6 Side Burner Grid 1
C7 Knob Bezel 1
C8 Side Burner Knob 1
C9 Side Burner 1
C10 Left Cabinet Panel 1
C11 Right Cabinet Panel 1
C12 Upper Support 1
C13 Door Handle 2
C14 Left Door 1
C15 Right Door 1
C16 Rear Panel 1
C17 Bottom Panel 1
C18 Front W heel Skirt 1
C19 Storage Unit 1
C20 Caster 2
C21 Lockable Caster 2
HARDWARE
D1 M6x35 Bolt 8
D2 ST4.0x10 Screw 21
D3 M6x15 Bolt 26
D4 M6 Nut 14
D5 M4x10 Bolt 6
D6 M4 Nut 3
Pre-Assembled Component
Quantity varies according to model purchased
Appearance, size, and construction may differ according to model purchased
Parts List
Quantity varies according to model purchased. Specifications subject to change without prior notice. For
more details on hardware, please see the corresponding ‘Hardware Reference Diagram’.
