14
19
20
Attach the side shelf assembly to the barbecue body using ST4.0x10 Screw (D1x2pcs) and
M6x15 Bolts (D4x4pcs) as shown.
D4
D1
step1
step2
step4
step3
D4
Insert the Drip Tray (B10) by sliding it underneath the barbecue body as shown.
B10

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Outback Meteor 4 and is the answer not in the manual?

Outback Meteor 4 Specifications

General IconGeneral
Burners4
IgnitionPiezo ignition
MaterialStainless steel
Side BurnerYes
Warming RackYes
TypeGas grill
Burner MaterialStainless steel
Grill Grate MaterialCast iron
Width54 inches
Depth60 cm
Height114 cm
Dimensions54 x 24 x 46 inches
