Connect the electrode wire to the Ignition Button (C6).
WARNING: BEFORE OPERATION, ENSURE BOTH MAIN BURNER AND SIDE
BURNER WIRES ARE CONNECTED TO PUSH BUTTON IGNITOR.
IF THE CIRCUIT IS NOT COMPLETED, THE IGNITOR WILL NOT SPARK!
Attach Side Shelf Panel (C9) onto Side Shelf (C8) using M6x15 Bolts (D4x2pcs) and
M6 Nuts (D6x2pcs).
C9
C8
Main burner wire
Side burner wire
