Unscrew the pre-assembled nut of the Ignition Button (C6).
Insert the Ignition Button (C6) into the hole at the side burner shelf panel and secure with the
pre-assembled nut.
C6
Feed the venturi tube of the Side Burner (C7) through the hole in bottom of the side burner shelf,
and fix side it onto side burner shelf using a M4x10 Bolt (D2) as shown. Make sure that the end of
venturi tube is set over the gas outlet of side burner valve.
C7
