Attach the side burner shelf assembly to the barbecue body using ST4.0x10 Screw (D1x2pcs)
M6x15 Bolts (D4x4pcs) as shown.
D4
step1
step2
step4
D1
step3
D4
Attach the side burner valve and Knob Bezel (C4) onto side burner shelf using M4x10 Bolts
(D2x2pcs) as shown. Press the Side Burner Knob (C5) onto side burner valve stem.
C5
C4
D2
