10
11
12
Carefully place the Barbecue Body (B1) onto the cabinet structure and fix using M6x40 Bolts (D5x8pcs)
as shown.
Attach Side Burner Shelf Panel (C2) onto Side Burner Shelf (C1) using M6x15 Bolts (D4x2pcs)
and M6 Nuts (D6x2pcs).
C2
C1
D4
D6

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Outback Meteor 4 and is the answer not in the manual?

Outback Meteor 4 Specifications

General IconGeneral
Burners4
IgnitionPiezo ignition
MaterialStainless steel
Side BurnerYes
Warming RackYes
TypeGas grill
Burner MaterialStainless steel
Grill Grate MaterialCast iron
Width54 inches
Depth60 cm
Height114 cm
Dimensions54 x 24 x 46 inches
