Oval LSF40 Series - Reed Switch Generator Provided

18
S-176-9-E
MODEL LSF41
MADE IN JAPAN
OVALM-Ⅲ
□40
25.8
2-Rp
1
／
8
33.8
8
MODEL LSF45
MADE IN JAPAN
OVALM-Ⅲ
□50
30.8
2-Rp
1
／
4
49.3
18.5
NOTE: See Sec. 4.2 (page 5) for lead-
wire connections.
■
Reed Switch Generator Provided
All dimensions in millimeters
■
Strainers (YS12 and 13)
Applicable meter sizes: 40, 41 and 45
Max. operating pressure: 1.96MPa
Body material: FCD450 (ductile cast iron) ※Material: H
SCS14A (stainless steel) ※Material: C
Net material : SUS304 (stainless steel) ※Material: H
SUS316 (stainless steel) ※Material: C
L
A
H
L
A
H
●
Outline (Material H)
Fig. 10.2
Fig. 10.3
●

Length Table
All dimensions in millimeters
Category Nominal size A Material L H (approx.) Net Mesh No.
YS12 (for Meter Sizes
40 and 41)
Rc1/8 (6mm)
※
1
H 110
※
2
60 200
C 95
※
2
50 200
YS13 (for Meter Size
45)
Rc1/4 (8mm)
H 80 60 2
00
C 65 50 2
00
NOTES
※
1:
Meter Sizes 40 and 41 with R1/4
×
Rc1/8
bushings.
(Bushings are contained in the same package as the strainer.)
※
2:
Dimensions with bushing installed (for reference purpose).
●
Meter sizes 40 and 41
●
Meter sizes 45
●
Outline (Material C)
