11. PRODUCT CODE EXPLANATION
●
Flow Mate
Item
Product Code
Description
Combination
① ② ③
④ ⑤ ⑥ ⑦ − ⑧ ⑨
38 39 40 4
1 45
Model L S F FLOW MATE (OVAL M-
Ⅲ
)
○ ○ ○ ○ ○
Meter Size
3 8 R
1/4 male
○
3 9
G1/8 (Rc1/4 depending on optionally available ttings.
A 300-mesh net is built in.)
○
4 0 Rp
1/8 (6mm)
○
4 1 Rp
1/8 (6mm)
○
4 5 Rp
1/4 (8mm)
○
Major Parts Materials
P Meter body (C) + Rotors (P: PEEK resin) Meter size 38 only
○ × × × ×
P Meter body (C) + Rotors (P: PPS resin) Meter size 39 only
× ○ × × ×
C Meter body (C) + Rotors (C)
× × × ○ ○
L Meter body (L) + Rotors (K)
× × ○ ○ ○
P Meter body (C) + Rotors (K)
× × ○ ○ ○
Process Connection (ttings)
0 − Less ttings
○ ○ ○ ○ ○
8 − Fittings provided (option)
× ○ ○ ○ ○
Pulse Generator
M MR sensor
○ ○ ○ ○ ○
R Reed switch (option)
× × ○ ○ ○
Pulse Type
1 Unfactored
○ ○ ○ ○ ○
2 Factored (MR sensor only)
× × ○ ○ ○
NOTE:
○
: Available
×
: Not available
●
Strainer
Item
Product Code
Description
① ② ③ ④ ⑤
Model Y S M-
Ⅲ
Strainer
Nominal Dia.
1 2 Rc
1/8 (Fits Meter sizes 40 and 41.)
2 3 Rc
1/4 (Fits Meter size 45.)
Material
H FCD450
C SCS
14A
