Oval PG30 - Page 6

T-518-11-E
6
Transmission Gear Box
Sym.No. Part Name Q 'ty
150 Transmission Gear Box 1 set
162 Ball Bearing B (LF1260ZZ) 1
167
Fitting Screw, Transmission Gear
Box
4
NOTE: Shaded area in the drawing
A replacement transmission gear box is available as
an assembly. When ordering this box, please specify
the gear ratio (e.g., 1/10 or 1/1) stamped on its plate.
Terminal Box Assembly
Sym.No. Part Name Q 'ty
301 Pressure-resistant packing casing 1
302 Pressure-resistant packing 1
303 Pressure-resistant packing washer 1
304 Pressure-resistant packing retainer 1
305 Terminal box housing 1
306 Terminal box housing lid 1
307
Fitting bolt, Terminal box housing
lid
4
308 O-ring (JIS G70) 1
309
Bolt, Terminal box housing
(M5 ×12)
4
310 Washer (M5) 4
311 Ground terminal screw (M4×8) 2
312 Washer (M4) 2
313 Crimp terminal (φ4) 8
314 Terminal block 1
Sym.No. Part Name Q 'ty
315
Flameproof enclosure rating
nameplate
1
316 Hex bolt for terminal (M4×18) 3
317 Washer (M4) 6
318 Washer (M4) 3
319 Nut (M4) 9
321
Terminal block fitting screw
(M4×10)
2
322 Washer (M4) 2
323
Washer, Terminal box housing lid
(M5)
4
325 Wiring instruction label 1
326
Pressure-resistant packing retain-
ing bolt (M5×15)
4
327 Washer 4
328 Cabtyre cable 1
329
Bolt, Pressure-resistant packing
casing (M5×12)
4
330 Washer (M5) 4
Ordering Instructions: Please supply us with the details of your order, which should include the owmeter
model, product No., Instruction manual No., symbol No., quantity desired, and part
name.
