Oval PG30 - Page 8

T-518-11-E
8
Model
Item
PG30 PG30EP
Output
pulses
System of
units
Model PG32 PG33 PG32EP PG33EP
Pulses per
revolution
100 P/rev 1000 P/rev 100 P/rev 1000 P/rev
Reduction gear ratio 2/1 20/1 2/1 20/1
Pulse generation HF generation and single pulse detection (3-wire system)
Certified explosionproof rating Standard Flameproof
Explosionproof rating  d2G4
Cable entry Rc (PT) 3/4 female G (PF) 3/4 female
Operating temperature range − 20℃ to +80℃
※ Standard supplies (DC power supplies) are available from OVAL. You can use one if required.
■
GENERAL SPECIFICATIONS
Number of gear teeth (toothed disk) 25 pole
Pulse generator unit
Type SHW - 1001
Color Green
Power Source ※ 12VDC ±10％
Current drain 30mA max.
Output signal levels
"0"= 0.5V max.
"1"= 6.2 to 7.6V (across 10kΩ resistive load)
Maximum operating frequency 2.5kHz (at sensing terminal)
Transmission length 1 kilometer max.
Output waveform Quasi rectangular wave ("0" / "1"= 35/65 to 60/40)
Hysteresis width 0.5mm min.
Electrical specifications
