"Hydrocontrol MTR" (lead-free) Installation & Initial Operation
21
Fig. 14:
Connecting measuring computer to valve
1
2
3
4
5
6
7
8
4
Legend
1 Measuring port (–)
2
Measuring port (+)
3 Measuringorice
4 Measuringneedles(accessories)
5 Bluemeasuringtube(accessory)
6 Redmeasuringtube(accessory)
7 Differential pressure sensor (accessory)
8 Differentialpressuremeter(accessory)
