Characteristic lines
Characteristic lines:
Characteristic lines of the Oventrop valves:
Indicated display
D
ouble regulating and commissioning valves “Hycocon V, VTZ, VPZ” DN 15 to DN 40 Hycocon V
R
egulating valves “Hycocon T, ETZ” DN 15 to DN 25 Hycocon T
R
egulating valves “Hycocon TM, HTZ” DN 15 to DN 40 Hycocon TM
Regulating valves “Hycocon TM, HTZ, ” Bronze kvs 5.0 DN 20 Hyco.TM RG
Regulating valves “Aquastrom C” DN 15 to DN 32 AquastromC
Double regulating and commissioning valves “Hydrocontrol R, VTR, VPR” DN 10 to DN 65 Hydroc. R
Double regulating and commissioning valves “Hydrocontrol G, VGC” DN 65 to DN 300 Hydroc. G
Double regulating and commissioning valves “Hydrocontrol F, VFC” DN 20 to DN 400 Hydroc. F
Double regulating and commissioning valves “Hydrocontrol FR, VFR” DN 50 to DN 200 Hydroc. FR
Double regulating and commissioning valves “Hydrocontrol FS, VFN” DN 65 to DN 300 Hydroc. FS
Double regulating and commissioning valves “G-86” DN 10 to DN 65 (Swedish market) G- 86
Double regulating and commissioning valves “RF-93” DN 20 to DN 300 (Swedish market) RF- 93
Regulating valve for chilled ceiling installations “Cocon 2TZ” kvs 0.45 DN 15 Coconkv045
Regulating valve for chilled ceiling installations “Cocon 2TZ” kvs 1.0 DN 15 Coconkv1.0
Regulating valve for chilled ceiling installations “Cocon 2TZ” kvs 1.8 DN 15 Coconkv1.8
Regulating valve for chilled ceiling installations “Cocon 2TZ” kvs 4.5 DN 20 Coconkv4.5
Four-port regulating valve “Cocon 4 TZ ” kvs 0.45 DN 15 Cocon4-045
Four-port regulating valve “Cocon 4TZ” kvs 1.0 DN 15 Cocon4-1.0
Four-port regulating valve “Cocon 4 TZ” kvs 1.8 DN 15 Cocon4-1.8
Brass metering station LF kvs 0.55 DN 15 met.st.LF
Brass metering station MF kvs 1.2 DN 15 met.st.MF
Brass metering station DN 15 to DN 50 /
Flanged stainless steel metering station DN 65 to DN 900 met.st.
Flanged cast iron metering station DN 65 to DN 300 met.st.CI
Characteristic lines of other valves:
Tour & Andersson (stored values taken from the catalogue 1999)
Flanged valve type “STAF” DN 20 to DN 300 STAF
Flanged valve type “STAF-SG” DN 20 to DN 300 STAF-SG
Flanged valve type “STAF-R” DN 65 to DN 150 STAF-R
Groove end valve type “STAG” DN 65 to DN 300 STAG
Female threaded valve type “STA” DN 15 to DN 50 STA
Female threaded valve type “STAD” DN 10 to DN 50 STAD
Male threaded valve type “STADA” DN 10 to DN 50 STADA
Female threaded valve type “STA-DR” DN 15 to DN 25 STA-DR
Crane (stored values taken from the catalogue 2000):
Double regulating and commissioning valves:
Fig.-No. D 930: DN 10 to DN 50 D930
Fig.-No. DM 930: DN 20 to DN 300 DM930
Metering stations/combinations metering stations/valves:
Fig.-No. D 901/D 941/D 931: DN 15 to DN 50
D901/D941/D931
Fig.-No. D 902/D 942: DN 15 D902/D942
Fig.-No. D 932: DN 15 D932
Fig.-No. D 933: DN 15 D933
Fig.-No. D 934: DN 15 D934
Fig.-No. DM 900/DM 940: DN 20 to DN 300 DM900/DM940
Fig.-No. DM 950: DN 50 to DN 300 DM950
