9
Component connection diagram/Battery case
Lockable plug
red
positioning
point
Sliding sleeve
Guide
Lockable plug-in connection between
flow meter and measuring head:
The plug is released by pushing back
the sliding sleeve!
The red positioning point indicates the
position of the guide when introducing
the plug into the guiding groove of the
jack bush on the lower side of the flow
meter.
