Owon CM2100 - Page 37

34
20.000MHz
0.001MHz
Duty Cycle(%)
[4]
0.1%-99.9%
(Typical
Value:Vrms=1V,f=
1kHz)
0.1%
±(1.2%+3dig)
0.1%-99.9%(≥1kH
z)
±(2.5%+3dig)
[1]When selecting 2A small current measurement function, read the reading after the
display value tends to be stable to ensure the accuracy of the value.
[2]In capacitance measurement mode, if the range of 20.00mF is selected, the
measurement time should last for more than 30 seconds.
[3]During the frequency measurement, the typical waveform is rectangular wave or sine
wave. The measured signal meets the following conditions:
[4]During the duty cycle measurement, the typical waveform is rectangular wave.
Note: During resistance and capacitance measurement, it is necessary to consider
the effect of the resistance of the test probe on the measured value.
Characteristics
Description
Maximum Reading
19999
Frequency（Hz）
(40-1000)Hz
Numerical Value Conversion
Rate
3 times/second
Automatic Range
√(Current excluded)
Opening Sizes
17mm
True Virtual Value
√
VFC
√
Numeric Data Retention
√
Zeroing Measurement
√
Relative Measurement
√
LCD Backlight
√
Automatic Shutdown
√
Buzzer ON/ OFF
√
NCV function
√
Low-Voltage Indication
√
Input Protection
√
Frequency
Amplitude (rms)
1Hz–20MHz
≥1V
