3.Quick Review
5
3.1.2 Rear
Panel
1
2
3
4
5
Figure 3-2
Rear Panel Overview
1
Air V
ent
Air vent.
2
Power Button
T
urn on
/off the in
strument.
3
Fuse
Power fuse.
4
AC
Power
Input
Jack
AC powe
r input interface.
5
Device
USB
Port
Upda
te the firmware
,
PC software cont
rol port.
8
10
