Owon VDS1022(I) User Manual

Dual CH
250MS/s
Single CH
500GS/s
VDS3104
Four CH
250MS/s
Dual CH
500MS/s
Single CH
1GS/s
Input
Input coupling
DC, AC , Ground
Input impedance
1MΩ±2%, in parallel with 10pF±5pF
Probe attenuation
factor
1X, 10X, 100X, 1000X
Max. input voltage
VDS1022I
VDS2052I
400V (PK-PK) (DC + AC
PK-PK)
VDS1022
VDS2052
VDS2062
VDS3102
VDS2064
VDS3104
40V (PK-PK) (DC + AC PK-PK)
Channel –channel
isolation
50Hz: 100 : 1
10MHz: 40 : 1
Time delay
between
channel(typical)
150ps
Horizontal
System
Sampling rate
range
VDS1022(I)
Dual CH
0.5S/s~100MS/s
Single CH
0.5S/s~100MS/s
VDS2052(I)
Dual CH
0.5S/s~250MS/s
Single CH
0.5S/s~250MS/s
VDS2062
Dual CH
0.5S/s~250MS/s
Single CH
0.5S/s~500MS/s
VDS3102
Dual CH
0.5S/s~500MS/s
Single CH
0.5S/s~1GS/s
VDS2064
Four CH
0.5S/s~125MS/s
Dual CH
0.5S/s~250MS/s
Single CH
0.5S/s~500MS/s
VDS3104
Four CH
0.5S/s~250MS/s
Dual CH
0.5S/s~500MS/s
Single CH
0.5S/s~1GS/s
Interpolation
(sin x)/x
Max Record length
VDS1022(I)
Dual CH
≤Max
sampling rate
5K
Single CH
VDS2052(I)
Dual CH
≤Max
sampling rate
5K
Single CH
VDS2062
Dual CH
≤Max
sampling rate
10M
Single CH
VDS3102
Dual CH
≤Max
sampling rate
10M
Single CH
VDS2064
Four CH
≤Max
sampling rate
5M
Dual CH
Single CH
VDS3104
Four CH
≤Max
sampling rate
5M
Dual CH
Single CH
33
