Owon XDM Series User Manual

2.Quick Start
7
Run/Stop When the trigger source is set as Auto, start or stop auto
trigger.
When the trigger source is set as Single,
the instrument
issues one trigger each time this key is pressed.
Math
Perform math operations (statistic, limits, dB/dBm, REL) on
the measurement results.
Utility Set the auxiliary system function, including Language,
Backlight, Clock, SCPI, Set to default, System information,
LCD test, Key test.
Port
Set Serial,
Trigger, Output connector, Net Type.
4
HI and LO Sense
Terminals
Signal input terminals, used for four-wire resistance
measurements.
5
HI and LO Input
Terminals
Signal input terminals, used for voltage, resistance,
continuity, frequency (period), capacitance, diode, and
temperature test measurements.
6
Range/Direction Keys When the Range softkey is shown on the right menu, you
can press the key to switch between auto and
manual range. Press to enable manual range, and
increase or decrease the measurement range.
When setting a parameter, press to move the cursor,
press to increase or decrease the value.
7
Current Terminal
Fuse
The rating is 10 A, 250 VAC.
To replace the fuse:
Turn off the multimeter and remove the power cord. Use a
flat-blade screw driver to turn the fuse holder
counter-clockwise, and pull out the fuse holder. Put the
new specified fuse into the fuse holder, and insert the
assembly back into the instrument, turning the fuse holder
clockwise to lock it in place.
8
AC/DC Current Input
Terminals
Signal input terminals, used for AC/DC current
measurements.
9
Power button
Turn on/off the multimeter.
