Owon XDM Series User Manual

6.Technical Specifications
49
Capacitance
[10
]
2.000 nF 200 nA 3 + 1.0 0.08 + 0.002
20.00 nF 200 nA 1 + 0.5 0.02 + 0.001
200.0 nF 2 μA 1 + 0.5 0.02 + 0.001
2.000 μF 10 μA 1 + 0.5 0.02 + 0.001
200 μF 100 μA 1 + 0.5 0.02 + 0.001
10000 μF 1 mA 2 + 0.5 0.02 + 0.001
Temperature
Temperature sensors under 2 categories supported -
thermocouple (ITS-90 conversion between B / E / J / K / N / R / S / T type), and
thermal resistance (RTD sensor conversion between PT100 and PT385 type)
[1]
Specifications are for 30-minute warm-up, "Low" measurement rate and calibration temperature
18℃ - 28℃.
[2] 20% over range on all ranges, except 1,000 V DCV, 750 ACV, 10 A DCI, 10 A ACI, 100 MΩ resistance, and
10000 μF capacitance.
[3] For each additional volt over ± 500 VDC add 0.02 mV of error.
[4] Specifications are for amplitude of sine wave input > 0.5% of range. For inputs from 1% to 5% of range and
<50 kHz, add 0.1% of range extra error. For 50 kHz to 100 kHz, add 0.13% of range extra error.
[5] 30 seconds OFF after 30 seconds ON is recommend for the continuous current that higher than DC 7 A or
AC RMS 7 A.
[6] Specifications are for amplitude of sine wave input > 0.5% of range. 0.1% errors will be added when the
range of input sine wave is 1% to 5%.
[7] Specifications are for 4–wire ohms function or 2–wire ohms using the relative operation of math. Without
relative operation, add ±0.20 Ω additional error in 2-wire ohms function.
[8] Specifications are for the voltage measured at the input terminals. The 1 mA test current is typical. Variation
in the current source will create some variation in the voltage drop across a diode junction.
[9] Except for special marks, the AC input voltage is 15% to 120% of range when ≤100 kHz and 30% to
120% of range when >100 kHz. 750 V range is limited to 750 Vrms.
[10]Specifications are for using the relative operation of math. Using of non-film capacitor may generate
additional errors. Specifications are for from 1% to 120% on 2 nF range and ranges from 10% to 120% on
other ranges.
XDM3041 Specifications
Accuracy: ± (% of reading + % of range)
[1]
Function Range
[2]
Frequency Range
or Test Current
Accuracy:
1 year
23℃±5℃
DC Voltage
600 mV
/ 0.02±0.01
6 V
60 V
600 V
1000 V
[3]
True RMS
AC Voltage
[4]
600mV, 6V, 60V, 600V, 750V
20 Hz – 45 Hz 2 + 0.10
45 Hz – 20 kHz 0.2 + 0.06
20 kHz – 50 kHz 1.0 + 0.06
50 kHz – 100 kHz
3.0 + 0.08
DC Current
600.00 μA
/
0.06 + 0.02
6.0000 mA 0.06 + 0.02
60.000 mA 0.1 + 0.05
600.00 mA 0.2 + 0.02
