6.Technical Specifications
[9] Except for special marks, the AC input voltage is 15% to 110% of range when ≤100 kHz, and 30% to
110% of range when >100 kHz. 750 V range is limited to 750 Vrms. When the measurement range of AC
voltage is in 600 mV range, multiply % of reading error x10.
[10]Specifications are for using the relative operation of math. Using of non-film capacitor may generate
additional errors. Specifications are for from 1% to 110% on 2 nF range and ranges from 10% to 110% on
other ranges.
XDM3051/XDM3041 Temperature Characteristic
Accuracy: ± (% of reading + % of range)
[1]
Function
Probe
Type
Probe Model
Working
Temperature Range
Accuracy:
1 year
23℃±5℃
Temperature
RTD
[2]
α=0.00385 -200℃ to 660℃ 0.16℃ 0.08+0.002
TC
[3]
B 0℃ to 1820℃ 0.76℃ 0.14℃
E -270℃ to 1000℃ 0.5℃
[1] Specification are for 0.5 hour warm-up, not include probe error.
[2] Specification are for 2-wire measure under "REF" operation.
[3] Built-in cold terminal compensation for thermocouple, accuracy is ±2℃.
Data Record Function
Manual Record Function
Press the front panel Save key to save current reading. The maximum number of readings is 1000.
Auto Record Function
Max number of readings
1 M for internal memory; 100 M for external memory
Max storage capacity
8 MB for internal memory; 800 MB for external memory
Sample interval
5 ms to 1000 s
Trigger
External Trigger
Input
Input level
TTL compatible (High level when left input
terminal is hanging in the air)
Trigger condition Selectable rising edge or falling edge
Input impedance
≥
20 kΩ in parallel with 400 pF, DC-coupled
Minimum pulse width 500 μs
VMC Output
Level TTL compatible
Output polarity Selectable positive or negative
Output impedance 200 Ω, typical
General Specifications
Dimension
(W x H x D): 235 mm × 110 mm × 295 mm
Weight
3.06 kg
