Utility Menu
You can set the parameters of the system-related functions and port parameters in utility
menu.
Press the panel key to view the instrument model, firmware version, serial
number, and checksum.
Language
Press the front panel key, press the Language softkey to switch display languages.
Backlight
Press the front panel key, press the Backlight softkey to adjust the brightness.
Timed shutdown
（Only for DC power supply model）
Press the front panel key, and then press the APO soft key to set the automatic
shutdown time. The selectable time is 0.5h, 1.0h, 1.5h, 2.0h, off (the instrument will not
automatically shut down if "off" is selected).
Communication interface settings
Press the front panel key, press the Next softkey to access the communication
interface setting menu.
Press the Baud softkey to select the desired baud rate from 2400, 4800, 9600, 19200,
38400, 57600 or 115200. The default is 115200. Make sure that the baud rate matches
that of the computer.
Press the Parity softkey, select the parity from None, Odd or Even. The default is None.
Press the Stop Bits softkey, select the stop bits from 1, 2.
The Data Bits is fixed to 8.
Clock
Press the front panel key, press the Next softkey to access the communication
interface setting menu.
Press the RTC softkey. The clock menu displays the date and time. The time always uses a
24-hour format (00:00:00 to 23:59:59).
Press the Set softkey to edit the date and time, Press the front panel key to move
the cursor, press or keys to increase or decrease the value. Press the OK
softkey to finish the clock setting.
Default
Press the front panel key, press the Next softkey to access the communication
interface setting menu.
