UNFOLDING THE DECK
1. Ensure no one is near the device, especially children and pets.
2. Unbuckle the straps at the front of the device. See Figure 2.1.
3. Unhook both ends of the deck straps from the latches located
in between the rear support beams of the XS1. See Figure 2.2.
4. Lower the deck using the deck handle located at the end of
the deck.
SETTING UP XS1 USER MANUAL
FIGURE 2.1
FIGURE 2.2
1. Disconnect all accessories from the device and re-
move the bench from the deck.
2. Ensure weight is unloaded and raise both slide han-
dles to their highest position.
3. Close both deck connection doors.
4. Use the deck handle to lift the deck to the UP po-
sition.
5. Hook both ends of the deck straps to the latches lo-
cated in between the rear support beams of the XS1.
See Figure 2.2.
6. After the deck is folded up, buckle the straps togeth-
er at the front of the device. See Figure 2.1.
FOLDING THE DECK (OPTIONAL)
You have the option to fold the deck after use to save space.
WARNING: The system must be powered on and the cables
must have maintenance tension.
STABILIZER LEGS
Two stabilzer legs located under the deck of the XS1 will be visi-
ble once the deck is folded up. The stabilizer legs are to remain
in place after installation.
WARNING: DO NOT remove or adjust the stabilizer legs. Keep
both stabilizer legs fully extended at all times.
