Ozito HDR-5000 - Know Your Product; Setup & Preparation

ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to
the online manual.
KNOW YOUR PRODUCT SETUP & PREPARATION
1. SIDE HANDLE & DEPTH ROD
The side handle provides additional comfort, control, and guidance
for the hammer drill.
1. Loosen the side handle.
Slide handle onto the collar
mount of the hammer drill.
3. To adjust, loosen the
side handle.
1 Depth Rod
2 Chuck
3 Side Handle
4 Gear Selector
5 Hammer Selector
6 Speed Selection Dial
7 Variable Speed Switch
8 Forward/Reverse Lever
9 Lock-On Button
HAMMER DRILL
2. Adjust to any position, 360°
around the collar mount.
Tighten side handle.
4. Adjust the depth
rod so the bit
extends beyond
the end of the rod
to the required
drilling depth.
5. Tighten depth rod by
tightening side handle.
required
drilling depth
Depth Rod
Side Handle
The depth rod helps to drill to a pre-determined depth.
CAUTION: Ensure the tool is disconnected from the power
supply before performing any of the following operations.
10 Chuck Key
ACCESSORIES
