Engine displacement: 25.4cc
Engine: Air-cooled, single-cylinder, 2-stroke
No load motor idling speed: 3,500/min (max. recommended)
Max. no load motor speed: 11,000/min
Fuel type: Unleaded fuel with 2-stroke oil
Fuel mixing ratio: 35:1
(1 Litre = 28.5ml oil added to 971.5ml unleaded petrol)
(5 Litres = 143ml oil added to 4.857L unleaded petrol)
Fuel tank capacity: 200ml
Chain bar oil tank capacity: 140ml
Spark plug type: LD L8RTF, NGK BM6A, Champion CJ8
Spark plug gap: 0.7mm
Oil feed system: Automatic
Sprocket wheel: 6-teeth x 9.53mm (3/8”) pitch
Guide bar type: Sprocket nose
Chain bar length: 305mm (12”)
Chain pitch: 9.53mm (3/8”)
Chain gauge: 1.3mm (0.050”)
Chain file: 3.96mm (5/32”)
Sound pressure level: 110 dB(A)
Tool weight: 3.7kg (including guide bar & chain)
Features: Safety chain brake
Auto chain stop
Anti vibration handles
2
SPECIFICATIONS - MODEL NO. OZPCS305A
