Corrective Maintenance
Power Source
Refer to the table below. Most malfunctions are simple and easy to correct.
Symptom Probable Cause Solution
No powe
r
to system Blown Fuse
Inspect and replace the fuse(s) located on the power source
rea
r
p
anel
Line cord unplugged Plug line cord into the appropriate AC outlet
Heater Assembly does not
heat
Open Heate
r
Contact PACE fo
r
assistance
Little or no air flow, heater
heats and blower is running
Kinked ai
r
hose
Change routing of air hose to remove
kinks
Little o
r
no vacuum Worn vacuum pump Replace vacuum pump. Contact PACE fo
r
assistance.
Vacuum Cup will not hold
component
Worn or broken
vacuum cup
Replace vacuum cup
Vacuum Pickup Rod binding
Vacuum Pickup rod is
bent
Contact PACE fo
r
assistance
Packing List
Item # Description Part Number
MBT 301
Only
MBT 301 E
Only
MBT 301
System
MBT 301 E
System
1 System Powe
r
Supply 8007-0480 1 0 1 0
2 System Powe
r
Suppl
y
(Export) 8007-0481 0 1 0 1
3 Powe
r
Cord, 115V 1332-0094-P1 1 0 1 0
4 Powe
r
Cord, 230V 1332-0093-P1 0 1 0 1
5 Hot Grip Removal Pad 1100-0307-P1 0 0 1 1
6 Fibe
r
Cleaning Tool 1100-0232 0 0 1 1
7 Cleaning Sponge Tool 1100-0233 0 0 1 1
8 Wire Brush 3/16 Diamete
r
1127-0014 0 0 1 1
9 Cable Marke
r
Kit 6993-0136-P1 0 0 1 1
10 Angle Bracket Kit 6018-0097-P1 0 0 1 1
11 PACE Screwdrive
r
1100-0230 0 0 1 1
12 SX-100 (Blue Connector) Kit 6993-0266-P1 0 0 1 1
13 MT-100 ((Blue Connector) Kit 6993-0264-P1 0 0 1 1
14 TD-100 (Blue Connector) Kit 6993-0263-P1 0 0 1 1
15 Operations Manual CD 5050-0459 0 0 1 1
Spare Parts
Item # Description PACE Part Numbe
r
1 Fuse, 2.0
A
, 125 V, Lag Time (MBT 301) 1159-0275-01-P5
2 Fuse, 1.25
A
, 230 V, Lag Time (MBT 301E) 1159-0275-02-P5
NOTE
Before calibration is attempted, the system should be allowed to reach set temperature and
stabilize for at least 15 seconds before calibrating.
