Tip & Temperature Selection
With any heating system, actual tip temperatures can differ greatly from temperature control settings. PACE’s
unique "Tip & Temperature Selection System" allows you to select and maintain True Tip Temperatures for any
size and type of tip and handpiece using the appropriate Tip Temperature Offset value.
Included with your system is a Chart Holder which holds Procedural Instructions, a Quick Reference Guide, a
Customer Log and a Chart(s) for each handpiece purchased. Follow the procedure given in the chart marked
Introduction when using the charts for each particular handpiece. Listed below is the summarized procedure.
PROCEDURE
1. Select the appropriate handpiece and corresponding chart for your application.
2. Using the chart, select the correct tip for your application.
3. Locate the corresponding recommended "Tip Offset Constant" shown in the shaded area on the chart.
In Tip Temp Offset Mode, enter this value for the Current Channel. Notice that the chart shows the
reference Set Tip Temperature as 371°C (700°F).
4. Exit the Tip Temp Offset Mode and enter the Tip Temp Set Mode. Select your desired Set Tip
Temperature.
5. Exit Tip Temp Set Mode. With PACE’s Dynamic Tip Temperature Offset system, the True Operating
Temperature of the working end of the tip will appear in the Digital Readout in Temperature Display
Mode (normal operation).
35
