52
Using your Sky digibox
Due to continued product improvement, this specification may change without notice.
General
Operating voltage: 230V AC ± 15%; 50Hz
Power consumption: 30W (max.)
Weight: 3.5kg (packed)
Dimensions (W x H x D): 305mm x 70mm x 222mm (not including connectors)
UHF modulator: CCIR PAL System I; Ch 21 to 69 (factory setting is 68)
Operating temperature range: 0°C to +50°C
Storage temperature range: –20°C to +60°C
Rear-panel connectors
MAINS INPUT: IEC 83 2-pin reversible
DISH INPUT: female F-type
TV SCART: SCART (composite video out; RGB out)
VCR SCART: SCART (composite video in/out; RGB in)
TELEPHONE LINE: RJ11
AERIAL IN: IEC 169-2 female
RF OUT - 1: IEC 169-2 male
RF OUT - 2: IEC 169-2 male
AUDIO OUT (LEFT and RIGHT): Phono
DIGITAL INTERFACE: General-purpose interface for future plug-in modules
RS-232: DB-9 female, data communications equipment (DCE)
EIA/TIA-232-E ITU-TV.28 115.2 kbit/s (max.)
If you connect earthed equipment to the RS-232
connector, you must use an approved screened cable.
The product complies with the following European Council Directives:
– 73/23/EEC (the Low Voltage Directive) as amended;
– 89/336/EEC (the EMC Directive) as amended;
– 1999/5/EC (the R&TTE Directive) as amended.
Specification
