Using one of the two baseline (default) profiles will provide a good starting point for
profile development. The reflow graph provides an excellent tool for monitoring
profile parameters and fine tuning or perfecting the profile development process.
When adjusting profile parameters “on-the-fly”, all changes are reflected immediately
on the profile development screen and graph.
Procedure
i. Mouse click on Profile for the Profile Development Screen. (Figure 7)
ii. Conduct steps vi thru v in paragraph 6a.
iii. Position the board so the red laser sighting light is roughly in the center
of the component. To move the board forward and back simply move
the PCB in the arms. To move the assembly left and right push the
release handle away from you and move the assembly. Pull the release
handle towards you to secure the assembly.
iv. Mouse click the cycle start button. Make adjustments as necessary.
v. If you’re finished, allow the PCB to cool and remove.
d. Profile Development Removal Procedure
i. Click on Development button.
ii. Install Vacuum tip and nozzle.
iii. Open file manager and set profile parameters.
iv. Save profile and close profile manager.
v. Click on start removal process button.
vi. Load PCB and align component with red laser light roughly in the center
of the component.
vii. Click on “OK” to Load PCB into board holder message.
viii. Use the X, Y, and Theta adjustments to center the target componet in
the camera screen.
ix. Click on the alignment complete button.
x. Click on the Lower Reflow Arm button.
xi. Adjust the nozzle height using the up and down Nozzle Head arrows.
xii. Click Start Heating button to begin profile.
xiii. Adjust as necessary.
Note – It is always good practice to run a new profile a second time without making any changes
to verify your results
7. Temperature Control
a. Heater temperatures are adjusted by changing the numbers on the profile screen
by clicking on the arrows, moving the temperature bars or using the up and down
arrows on the keyboard.
8. Available Nozzles/Accessories/Optional Items
a. A complete list of nozzles and accessories is on our web site,
www.paceworldwide.com
9. Maintenance
Caution: Disconnect the main power supply and computer cables before
opening the BGA workstation door, replacing any component or before
performing any routine maintenance.
a. Cleaning the Blower Filter. Clean the filter every three months.
i. Open the cover on the back of the TF 1700 or TF 2700. (Figure 21)
ii. Identify the blower pump, mounted on the base of the machine.
