Pace TF 1700 - Page 37

System Operations Manual
www.paceworldwide.com
Page 37 of 50
11. Remove the pick solenoid sensor.
12. Remove the ground wire that is located on the left side of the heater assembly.
Requires 3/32” hex
wrench
Figure 30
Figure 31
Requires 3/32” hex
wrench
Requires 3/32” hex
wrench
10. Remove the four pick solenoid
sensor cover screws.
