Packd C4 Series - Page 15

15 | C4 A s s e m b l y & I n s t a l l a t i o n G u i d e
Without Floor Kit
• Measure and mark the center of the
Shelving Unit.
• Place the Center Support so that it is
centered on the Shelving Unit using square
to locate it perpendicular to the floor.
• Fasten Center Support to Shelving Unit.
• Fasten Center Support to floor. Use 1/4
Nylon Spacers where necessary.
Tools Used:
Cordless Impact Driver
3/8” Nut Driver Bit
Marker
Tape Measure
Large Square
Hardware Used:
5 x Hex Washer Head Screw #14 x 3/4”
2 x 1/4” Nylon Spacer
1/4” Nylon Spacer
