Packd C4 Series - Marking for Plus Nut Installation

7 | C4 A s s e m b l y & I n s t a l l a t i o n G u i d e
2 MARKING HOLES FOR PLUS NUTS
Mark Plus Nut Locations
Once the mounting brackets are secured to the end panels, marks can be made for installing Plus Nuts
onto the vehicle. (See page 11 for vehicles with Wall Kits)
Mark 4 holes onto the
horizontal rim of the
vehicle as shown
Tools:
Marker
Mark
