14 | C4 A s s e m b l y & I n s t a l l a t i o n G u i d e

6 INSTALLING CENTER SUPPORT

For Shelving Units 72” or longer, a Center Support will need to be installed.

With Floor Kit

• Measure and mark the center of the

Shelving Unit.

• Place the Center Support so that it is

centered on the Shelving Unit using square

to locate it perpendicular to the floor.

• Fasten Center Support to Shelving Unit.

• Fasten Center Support to Subfloor.

Tools Used:

Cordless Impact Driver

3/8” Nut Driver Bit

Marker

Tape Measure

Large Square

Hardware Used:

5 x Hex Washer Head Screw #14 x 3/4”
