Packd C4 Series - Attaching Shelf Unit to Vehicle Wall

10 | C4 A s s e m b l y & I n s t a l l a t i o n G u i d e
4 FASTENING SHELF UNIT TO THE WALL
Without Wall Kit
Lift the assembled shelf unit back into place ensuring that the slots in the mounting brackets line up with
the Plus Nuts in the wall.
Fasten the Shelf Unit to the wall.
Tools Used:
Cordless Impact Driver
3/8” Nut Driver Bit
Hardware Used:
4 x 5/16-18 x 1-1/4” Hex Bolt
4 x 5/16 Flat Washer
4 x 5/16 Lock Washer
4 x 5/16 Plus Nut
