Part 6 - Appendix
91
Connectors
Video In Ethernet: 9 ports
Camera Power Out Ethernet: 8 ports
Monitor Out
HDMI: 1 HDMI
VGA: 1 DB15
Audio In 1 RCA connector
Audio Out 1 RCA connector
Alarm Terminal block
Ethernet Port 1 RJ-45
eSATA Ports 4 eSATA Ports (SmartIP-PD Series), 2 eSATA Ports (SmartIP-SD, SmartIP-SDX Series)
RS232 Serial Port Terminal block, text insertion (POS/ATM)
RS485 Serial Port Terminal block, telemetry control, remote control keyboard (programmable)
IR Remote Control Port Remote Control
USB Ports 2 x USB 2.0 (5V, less than 0.5A)
Storage
Internal Storage 6 SATA2 bays (SmartIP-PD Series), 4 SATA2 bays (SmartIP-SD, SmartIP-SDX Series)
External Storage 4 eSATA ports (SmartIP-PD Series), 2 eSATA ports (SmartIP-SD, SmartIP-SDX Series)
Clip Copy Device USB Storage Device (USB HDD, USB Memory, etc.)
Some hard disks may not function properly when mounted on to this product. Refer to the compatibility chart below before
mounting any additional hard disk on to the product. Hard disk compatibility chart is subject to change without notice.
Contact your retailer for the latest compatibility chart.
Storage Manufacturer Model Note
1TB
Seagate ST31000322CS
Western Digital WD10PURX-64D85Y0
TOSHIBA DT01ACA100
2TB
Seagate ST2000VM003
Western Digital WD20PURX-64P6ZY0
TOSHIBA DT01ACA200
3TB
Seagate ST3000VX000
Western Digital WD30PURX-64P6ZY0
TOSHIBA DT01ACA300
4TB Western Digital
WD40PURX-64GVNY0
