How to run the machine
20
Subject to change without notice
3.4 Shaft
Upon loosening clamping lever 4.1, the shaft’s width is adjusted with handwheel 4.2.
Upon loosening clamping lever 4.3, the shaft walls 4.4 are now adjusted to the format.
Ensure that this is carried out at the narrowest position. For this, turn the vibration plate gear
with a No. 6 socket head cap screw key (see 4.5).
4.1
RIGHT WRONG
3. 3 . 2
3. 3. 1
3.
2
.a
4.3
4.4
