4.5 Sensor B 7
Sensor Position/Name Adjustment
B7 Speed counter infeed belts The slot disc must rotate centrally in the
sensor’s slot. N.B. Bearing damage to the slot
disc shaft will result in destruction of the sensor
4.6 Sensor B 8 B 9 and B 11
Sensor Position/Name Adjustment
B8
B9
B11
Counter lane 1
Counter lane 3
Counter lane 2
The distance to the paper must be approx. 20-
30mm
B7
B11
B9
B8
