Sensor Technology
4
Subject to change without notice
37
4.14 Sensor B 39 and B 40
Sensor Position/Name Adjustment
B39 Pusher ground position When the package lift ejector is moved
manually, at least 75% of Sensor B39 must be
covered by the actuator. The distance between
sensor and actuator 0,5 – 1 mm
B40 Pusher working position When the package lift ejector is moved
manually, at least 75% of Sensor B40 must be
covered by the actuator. The distance between
sensor and actuator 0,5 – 1 mm
B39 B40
2930
