13
Code list TC166
52
Subject to change without notice
Code
nr.
Password
protected
Set
value
Unit Title Description
119 no 0
1
2
3
Language 1
Language 2
Language 3
Language 4
German
German
English
Dutch
120 no 0 Photocell counter lane (B8, B9, B11), 0 = all, 1, 2 or 3
121 yes 2000 1/1000 sec Delay 16 Welding protection
122 no 2 1/100 sec Delay 6 After reaching the pre-selected batch piece value, the elevation table moves into the
intermediate position and stops after photocell B18 is released. Photocell B18 must remain
free for at least this period of time before the elevation table stops.
123 no 50
1/100 sec Delay 7 After reaching the intermediate position, the elevation table moves upwards until press
sensor B5 responds. This is the maximum value during which it moves up. After this value,
the elevation table is stopped and the welding process is triggered independently from B5.
124 no 0 1/100 sec Delay 8 Only in connection with the option "Batch level compensator". Usually, the batch level
gates are set so that they retract when they reach the intermediate position. This retraction
can be delayed by increasing this value.
125 yes 100 1/100 sec Delay 9 After activation, the pressing guides must be extended at the latest after this length of time
(B3). If not, the machine will stop with Error 16.
126 no 1 Running out of banding, the machine stops with Error 42 (see also code 127).
127 no 200 cycles Cycle selection after display of end of banding until machine stops with Error 42
128 no 0 each Counter Only in connection with the option "Batch level compensator". After reaching this value, the
batch level gates are set by the batch counter.
129 no min 1 Flashing rate of signal indicator
130 no 0
1
not active
active
Operation of the banding delivery without package lift
Operation of the banding delivery with package lift.
131 no 1
0
left
right
Operation of the package lift on the operator side
Operation of the package lift on the control box side
132 no 1,2,3,4,5
o. 6
Packing cycle The package lift will start after thiese cycles have elapsed
133 yes 50 1/100 sec Delay 10 After ejecting the banded stacks, the side loader will start after this amount of time has
elapsed.
134 yes 50 1/100 sec Delay 11 After conveying the banded stacks to the package lift using the side loader, the lift table will
start after this value has elapsed.
