PTV 33/44/55/66 Owner’s Manual
Rev. 1.0 21
7.4 Auxiliary 3-Button Hand Held Control
The auxiliary 3-Button Handheld Control is a secondary control used for troubleshooting the PTV. The
handheld control can be found on the pump side of the enclosure as shown below. The control is fully opera-
tional and can control the liftgate in the same way as the main controls located at the column, however the
control is not intended for everyday use.
Pump & Motor
Side of Enclosure
Lift
Lower
(Push once for gravity down,
twice within 5 seconds for
power down).
Open the Platform
(Two Button Operation,
Press Simultaneously)
Close the Platform
(Two Button Operation,
Press Simultaneously)
Battery Side
of Enclosure
Remote
Holster
3-Button Auxiliary
Remote w/30 ft.
Straight Cord
To Next Page
