PTV 33/44/55/66 Owner’s Manual
Rev. 1.0 24
7.6 Aluminum Retention Ramp
1. Lower the platform to the ground. Turn the retainer latch clockwise to release the ramp. Use the ARR handle
on the side to open the retention ramp.
2. Load platform. To use the ramp as a load retention, stop, place the ramp 90° to the platform and use the
chain to secure the ramp.
3. Lower the platform down to the ground and remove the chain from the retaining notch. Place the ARR back
in its original position and turn the retainer latch enough to allow the ramp to lay between the platform and
retainer. Proceed to storing the platform.
