Palfinger PTV 35 - Hydraulic Schematic

PTV 33/44/55/66 Owner’s Manual
Rev. 1.0 41
9.7 Hydraulic Schematic
HYDRAULIC, SCHEMATIC, PTV
BUCHER PUMP (
90-1118-001)
15939 Piuma Ave. Cerritos, CA 90703
M
207
BAR
3000
PSI
AB
69 BAR
1000
PSI
C
D
1.72
CC/REV
0.105
IN³/REV
T1
P1
M
1.72
CC/REV
0.105
IN³/REV
S1
S2
S5
S4
S3
M+S1 = LIFT
M+S2+S5 = POWER DOWN
S5 = GRAVITY DOWN
M+S4 = TILT OPEN
M+S3 = TILT CLOSE
LIFT CYLINDER 1
LIFT CYLINDER 2
OPEN CLOSE
CYLINDER
SECONDARY PUMP UNIT
(OPTIONAL)
PRIMARY PUMP UNIT
RESERVOIR
2.6 GPM
