palintest Lumiso Chlorine User Manual

Insert new batteries in the
same way, pushing towards the
negative contact, but this time,
down at the positive end.
Note the polarity guidance in
the compartment.
4
5
The batteries are held firmly
in place by the clips to enhance
Lumiso’s resilience to physical
shock.
To remove the batteries, push
them towards the negative
contact and lift the positive end.
3
The cover will lift and, if
necessary, the captive screw can
be further loosened so the cover
can be removed completely.
4848

palintest Lumiso Chlorine Specifications

General

Instrument	Single wavelength, direct-reading colorimeter
Optics	LED light source optical system with narrow band wavelength filters and photodetectors
Test Cells	25 mm diameter tubes
Wavelengths	Automatic wavelength selection of 530 nm
Wavelength Tolerance	± 2 nm
Filter Bandwidth	5 nm
Blank/Zero setting	Held in memory, but instrument will prompt for re-blanking after 50 minutes
LCD Display	226 x 138 pixel with adjustable backlight
Results Log	50 results, with date, time and label
Operating Conditions	0 – 50°C 90% Relative Humidity (non-condensing)
Waterproof Rating	IP67 (Waterproof)
Power Supply	3 x 1.5V AA batteries USB Port 6V max, 200mA max (DC)
USB Port	Micro USB Type B

Weight and Dimensions

Size	163 x 70 x 45 mm
Weight	275g (including batteries)
