palintest Lumiso Chlorine User Manual

4949
Secure the captive screw so that
it gently holds the cover in place.
Please Note: Do not tighten the
screw excessively. The level of
torque applied to this screw has
no affect on the performance of
the waterproof seal.
Replace the cover, hinge end first.
Then firmly push the cover down
until it is parallel to the case as
below. This ensures that the
waterproof seal is complete.
7
6
Thank you for choosing your Palintest Lumiso
Photometer. For any further questions or
information on Lumiso consumables and
accessories please visit www.palintest.com

palintest Lumiso Chlorine Specifications

General

Instrument	Single wavelength, direct-reading colorimeter
Optics	LED light source optical system with narrow band wavelength filters and photodetectors
Test Cells	25 mm diameter tubes
Wavelengths	Automatic wavelength selection of 530 nm
Wavelength Tolerance	± 2 nm
Filter Bandwidth	5 nm
Blank/Zero setting	Held in memory, but instrument will prompt for re-blanking after 50 minutes
LCD Display	226 x 138 pixel with adjustable backlight
Results Log	50 results, with date, time and label
Operating Conditions	0 – 50°C 90% Relative Humidity (non-condensing)
Waterproof Rating	IP67 (Waterproof)
Power Supply	3 x 1.5V AA batteries USB Port 6V max, 200mA max (DC)
USB Port	Micro USB Type B

Weight and Dimensions

Size	163 x 70 x 45 mm
Weight	275g (including batteries)
