Note: Highlighted parameters indicate that the specific self-
test failed based on the expected values.
To view the Diagnostic 2 screen, which shows information about your
MG2 series gage:
Step 1: Press [2ndF][ ](Setup) to display the setup tabs.
Step 2: Use the [ , ] keys to highlight the DIAG2 tab.
The following results are displayed:
Gain Internal Calibration
BLK, DET, SMP Internal Blank, Detector and
Sampler Test
Thresh Cal
(RCVR1)
Threshold Calibration Test
Receiver 1
Thresh Cal
(RCVR2)
Threshold Calibration Test
Receiver 2
Table 9-1: DIAG1 Results
